| Процесор, тип: | AMD |
| Чипсет: | AMD B450 |
| Сокет: | Socket AM4 |
| Памет, тип: | DDR4 |
| Памет, честота: | 3600 MHz / 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory; Dual channel memory architecture; Support for DDR4 3600(O.C.)/3466(O.C.)/3200(O.C.)/2933/2667/2400/2133 MHz memory modules; Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode); Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for Extreme Memory Profile (XMP) memory modules |
| Памет, слотове: | 4 |
| Максимална памет: | 128 GB |
| Твърд диск, характеристики: | 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support) (M2A_SOCKET); 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 PCIe 3.0 x2 SSD support)(M2B_SOCKET); 6 x SATA 6Gb/s connectors; Support for RAID 0, RAID 1, and RAID 10 |
| Raid: | Да / RAID 0, RAID 1, and RAID 10 |
| Мрежа: | Realtek® GbE LAN chip (10/100/1000 Mbit) |
| Безжична мрежа: | Не |
| Звук: | Realtek® ALC892 codec; High Definition Audio; 2/4/5.1/7.1-channel; Support for S/PDIF Out |
| Слотове: | 1 x PCI Express x16 slot, running at x16 (PCIEX16)(Note); * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. (The PCIEX16 slot conforms to PCI Express 3.0 standard.); 1 x PCI Express x16 slot, running at x4 (PCIEX4); * The PCIEX4 slot shares bandwidth with the PCIEX1_2 slot. The PCIEX4 slot operates at up to x2 mode when the PCIEX1_2 slot is populated. The PCIEX4 slot operates at up to x4 mode when the PCIEX1_2 is empty. 2 x PCI Express x1 slots; (The PCIEX4 and PCIEX1 slots conform to PCI Express 2.0 standard.) |
| Слот М.2: | 2 |
| Портове: | 1 x PS/2 keyboard/mouse port; 1 x DVI-D port; 1 x HDMI port; 4 x USB 3.1 Gen 1 ports; 4 x USB 2.0/1.1 ports; 1 x RJ-45 port; 6 x audio jacks |
| BIOS: | 1 x 128 Mbit flash; Use of licensed AMI UEFI BIOS; PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Форм фактор: | ATX |
| Гаранция: | 36 м. |
