| Процесор, тип: | Intel |
| Чипсет: | Intel B760 / Intel® B760 Chipset |
| Сокет: | LGA1700 |
| Памет, тип: | DDR5 |
| Памет, слотове: | 4 |
| Максимална памет: | 128 GB |
| Твърд диск, характеристики: | Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports*; Intel® 13th & 12th Gen Processors; M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode); Intel® B760 Chipset; M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode); 4 x SATA 6Gb/s ports |
| Мрежа: | 1 x Realtek 2.5Gb Ethernet; TUF LANGuard |
| Безжична мрежа: | Не |
| Звук: | Realtek 7.1 Surround Sound High Definition Audio CODEC; - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking; - Supports up to 24-Bit/192 kHz playback "; Audio Features; - Audio Shielding; - Rear optical S/PDIF out port; - Premium audio capacitors; - Dedicated audio PCB layers |
| Слотове: | Intel® 13th & 12th Gen Processors; 1 x PCIe 5.0 x16 slot; Intel® B760 Chipset; 1 x PCIe 4.0 x16 slot (supports x4 mode); 1 x PCIe 4.0 x1 slot |
| Слот М.2: | 2 |
| Портове: | 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C®); 2 x USB 3.2 Gen 2 ports (2 x Type-A); 3 x USB 3.2 Gen 1 ports (3 x Type-A); 2 x USB 2.0 ports (2 x Type-A); 1 x DisplayPort; 1 x HDMI™ port; 1 x Realtek 2.5Gb Ethernet port; 5 x Audio jacks; 1 x Optical S/PDIF out port |
| BIOS: | 128 Mb Flash ROM, UEFI AMI BIOS |
| Форм фактор: | Micro ATX / mATX Form Factor; 9.6inch x 9.6 inch ( 24.4 cm x 24.4 cm ) |
| Гаранция: | 36 м. |
